USB RS232 860-960mhz RFID Desktop Reader EPC CLASS1 G2 iso 18000-6b Wiegand

Name: USB RS232 860960mhz RFID Desktop Reader EPC CLASS1 G2 iso 180006b Wiegand
Brand: ZKHY
Price: 1 USD

China USB RS232 860-960mhz RFID Desktop Reader EPC CLASS1 G2 iso 18000-6b Wiegand wholesale

Brand Name : ZKHY

Model Number : ZK-RFID107

Certification : CE Rohs FCC

Place of Origin : China

MOQ : 1pc

Price : USD, Negotiable

Payment Terms : T/T ，western Union，Paypal

Supply Ability : 10,000pcs per month

Delivery Time : 3~7 working days after received your payment

Packaging Details : Packed in carton

Protocol : (EPC C1G2) , ISO18000-6B/6C

Communication Interface : RS232, RS485, wiegand24/36,RJ45,

Size : 160mmx108mmx40m

Read Distance : more than 300mm

Working Mode : Answer mode,Active mode

power : maximum 30dbm

work frequency : 902~928MHz customized

Antenna : Built-in transmitting

N.W : 200g

Contact Now

USB RS232 860-960mhz RFID Desktop Reader EPC CLASS1 G2 iso 18000-6b Wiegand

ZK-RFID107 is a high performance Multiple Protocol UHF RFID Reader. It is designed upon fully self-intellectual property. Based on proprietory efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, attendance system, anti-counterfeit and industrial production process control system.

Working frequency: 902~928MHz customized
Read/write distance: read distance 0-600MM, write distance: 0-30MM
Support Protocol: supports UHF EPC Gen2(ISO18000-6C), ISO18000-6B protocol electronic tags
Support Interface: supports RS232, Wiegand Interfaces
Working mode: FHSS or Fixed frenquency transmission.
Output power: maximum 30dbm(adjustable)
Provide DLL and Demonstration Software source code to facilitate further development.
Low power disspation with single +6V DC power supply.
Support Interactive and Active working mode.
Output format and parameters can be set under active working mode.
160mmx108mmx40mm Net weight: 200g

CHARACTERISTICS

Absolute Maximum Rating

ITEM	SYMBOL	VALUE	UNIT
Power Supply	VCC	15	V
Operating Temp.	T_OPR	-10~+60	°C
Storage Temp.	T_STR	-25~+80	°C

Electrical and Mechanical Specification

Under T_A=25°C,VCC=+9V unless specified

ITEM	SYMBOL	MIN	TYP	MAX	UNIT
Power Supply	VCC	6	9	12	V
Current Dissipation	I_C		400	700	mA
Frequency	F_REQ	860	860~868 902~928	928	MHz
Effective Distance^*	Dis	0	100	500	mm

* Effective distance depends on protocol, tag and environment.101
